Cisco2911/K9 2911 Integrated Services Router With Gigabit Ethernet Port
Rough overview:
New and Original Cisco Router 2900 series CISCO2911/K9
Product Description
Device Type Router
Enclosure Type Rack-mountable - modular - 2U
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol IPSec, L2TPv3
Routing Protocol
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing,
IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing,
policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast
Remote Management Protocol SNMP, RMON, TR-069
Compliant Standards
IEEE 802.3, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah,
IEEE 802.1ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 43.8 cm x 30.5 cm x 8.9 cm
Items Detais:
| General Information |
| Manufacturer Part Number | CISCO2911/K9 |
| Manufacturer | Cisco Systems, Inc |
| Product Name | 2911 Integrated Services Router |
| Product Type | Multi Service Router |
| Brand Name | Cisco |
| Interfaces/Ports |
| Number of Ports | 3 |
| Gigabit Ethernet Port | Yes |
| Interfaces/Ports | 3 x RJ-45 10/100/1000Base-T Network WAN |
| Interfaces/Ports | 1 x RJ-45 RS-232 Auxiliary Management |
| Interfaces/Ports | 1 x RJ-45 RS-232 Console Management |
| Interfaces/Ports | 1 x Type B USB Management |
| Interfaces/Ports | 2 x Type A USB |
| I/O Expansions |
| Number of Expansion Slots | 10 |
| Expansion Slots | (4 Total) HWIC |
| Expansion Slots | (2 Total) Compact Flash (CF) Card |
| Expansion Slots | (2 Total) Services Module |
| Expansion Slots | (2 Total) PVDM |
| Modules | Not Included |
| Memory |
| Standard Memory | 512MB |
| Maximum Memory | 2GB |
| Memory Technology | DRAM |
| Flash Memory | 256 MB |
| Power Description |
| Input Voltage | 220V AC |
| Input Voltage | 110V AC |
| Input Voltage Range | 100V AC to 240V AC |
| Physical Characteristics |
| Form Factor | Rack-mountable |
| Form Factor | Wall-mountable: |
| Dimensions | 3.50" Height x 17.25" Width x 12" Depth |
| Weight | 18 kg |
